Where are Power/USB locations

Lize

Active Member
Premium Account
Member ID
#2742
Messages
354
Reactions
961
Points
117
City
Bury St Edmunds
State
Non-US
Country
United Kingdom
Vehicle
2019 Challenger WB Redeye
#1
I've a 2019 Redeye on the way, hoping for test/registration to be complete by 5th August :love:

The insurance company insists on a tracking device being fitted. They've agree to a stand alone plug in box sort as I wasn't keen on a chimp chopping into the wiring loom.

Problem is now I look at the boxes the battery life is really poor, some claim 90 days on standby but they all seem to get bad reviews. Even though they send a text when power is low I'll no doubt still forget to charge it up. I don't really want to hook it up from the battery with ignition feed.

What I'm wondering and hope you can help with is where are any USB ports, are there any in the back of the centre console or similar location where I am unlikely to want to use it? Thinking I could take the USB socket out (replace with a blank) and use for the box and also hide it in the console perhaps.

Other than that I'm contemplating using a power bank to hopefully reduce number of charges but then I'll have to locate it somewhere accessible and it doesn't seem very secure just to chuck it under a seat or in the boot.

Sorry if in the wrong section, wasn't sure where to post so chose interior.
Thanks



SilverBillet

3000 Posts Club
Founding Member
Donating Member
Member ID
#1009
Messages
3,109
Reactions
11,404
Points
252
City
The Villages
State
FL
Country
United States
Vehicle
2021 Jeep GC 5.7 TrailHawk
#2
What kind of tracking device do you think works off of a USB? I think it has to be hardwired in? I cannot believe the insurance company can require you to have a tracking device? How much discount do you get with a tracking device? I would get a LoJack installed. I assume you can get that or something like it in GB? The installers can hide it.



OP
Lize

Lize

Active Member
Premium Account
Member ID
#2742
Messages
354
Reactions
961
Points
117
City
Bury St Edmunds
State
Non-US
Country
United Kingdom
Vehicle
2019 Challenger WB Redeye
Thread Starter #3
Zero discount, I've tried quite a few insurance companies and specialist brokers, I've been unable to find anyone who will insure it without. In UK vehicle value £100K+ needs a tracker and some even insist on £50K+.

In my mind by saying I could fit a black box type one means they are effectively willing to cover without. On a recorded call the operator even suggested I could get a cheap one of Amazon and pop it under the seat :LOL:.

Something along these lines:
https://www.amazon.co.uk/Locator-Po...8C4E&pd_rd_wg=lniNE&ref_=pd_gw_ci_mcx_mr_hp_d
Not looked into detail but can get data only SIM for £2 a month, need to look into boxes a bit more as some only work on 2G.



OP
Lize

Lize

Active Member
Premium Account
Member ID
#2742
Messages
354
Reactions
961
Points
117
City
Bury St Edmunds
State
Non-US
Country
United Kingdom
Vehicle
2019 Challenger WB Redeye
Thread Starter #4
PS. I don't want a tracker, just something to satisfy requirement but if it were to get stolen it needs to work or insurance will not pay out.



Hunter

7000 Posts Club
Staff Team
Founding Member
Premium Account
U.S. Army Veteran
Donating Member
HFCOTM
Member ID
#957
Messages
7,935
Reactions
19,281
Points
402
City
Moss Point
State
MS
Country
United States
Vehicle
2019 Challenger Hellcat
#5
Cars come with uconnect 1st year. That in itself is a tracking device.
Challengers have a USB hub inside armrest.
Be careful.
Some hubs go straight to battery.
@Diboblo might be able to give you more info.



OP
Lize

Lize

Active Member
Premium Account
Member ID
#2742
Messages
354
Reactions
961
Points
117
City
Bury St Edmunds
State
Non-US
Country
United Kingdom
Vehicle
2019 Challenger WB Redeye
Thread Starter #6
Thanks, the uConnect is an interesting idea but might not work in UK, can't create an account as only has European Alfa and Fiat options so no Apple Watch restart etc on my Ram.

Will be cautious about the USB straight to battery part, maybe just pop one on a power bank to start with and see how I get along.



DGatzby

5000 Posts Club
Founding Member
Premium Account
U.S. Air Force Veteran
Donating Member
HFCOTM & HFCOTY
Member ID
#797
Messages
5,588
Reactions
31,223
Points
402
City
SW Twin Cities
State
MN
Country
United States
Vehicle
2019 Dodge Challenger Redeye WB
#7
I think the cig lighter port in the console compartment is 100% power, just get an adapter for a USB and plug it in there. They will find it quick if it is stolen, but that is the easy place to get power when the car is off for the device. The USB ports die when the car is off.



OP
Lize

Lize

Active Member
Premium Account
Member ID
#2742
Messages
354
Reactions
961
Points
117
City
Bury St Edmunds
State
Non-US
Country
United Kingdom
Vehicle
2019 Challenger WB Redeye
Thread Starter #8
Thanks very much, I'm tending to think it would be better to only charge while on the move and avoid any possibilities of it going wrong and causing battery drain. I'm not going to leave it parked for any great length of time so if I get one with more than a few days standby it should be enough topping it up while driving.

I'll go ahead and look at them in a bit more detail and get one on order.



SilverBillet

3000 Posts Club
Founding Member
Donating Member
Member ID
#1009
Messages
3,109
Reactions
11,404
Points
252
City
The Villages
State
FL
Country
United States
Vehicle
2021 Jeep GC 5.7 TrailHawk
#9
What do other people in the UK do to resolve this? Around here, we have shops that specialize in stereo and alarm installations. You must have some shops like that in the UK? A do-it-yourself install may be penny wise but pound foolish?



Stormtrooper1320

Poster Club Hall of Fame
Founding Member
U.S. Marine Veteran
Member ID
#1068
Messages
10,407
Reactions
35,580
Points
352
City
Bran
State
Non-US
Country
Romania
Vehicle
Panzerkampfwagen 150
#10
Zero discount, I've tried quite a few insurance companies and specialist brokers, I've been unable to find anyone who will insure it without. In UK vehicle value £100K+ needs a tracker and some even insist on £50K+.

In my mind by saying I could fit a black box type one means they are effectively willing to cover without. On a recorded call the operator even suggested I could get a cheap one of Amazon and pop it under the seat :LOL:.

Something along these lines:
https://www.amazon.co.uk/Locator-Po...8C4E&pd_rd_wg=lniNE&ref_=pd_gw_ci_mcx_mr_hp_d
Not looked into detail but can get data only SIM for £2 a month, need to look into boxes a bit more as some only work on 2G.
How about something like this......
it looks like you could plug it into the usb on your car and leave it hooked up. If you're going tod rive every few days, shouldn't be an issue.

https://www.amazon.co.uk/SpyTrack-N...E8XYMC7CZYP&psc=1&refRID=R2TWZW9H6E8XYMC7CZYP



HWDan

1000 Posts Club
Founding Member
Premium Account
Donating Member
Member ID
#1183
Messages
1,127
Reactions
3,330
Points
162
City
Home of the Hellcat
State
Non-US
Country
Canada
Vehicle
2017 Charger SRT 392
#11
Sending out the "hellcat" signal to other UK members like @The Englishman, surely he may have experience with these trackers to add here.



The Englishman

500 Posts Club
Founding Member
Premium Account
Donating Member
9 Second Best E/T
HFCOTM
Member ID
#1082
Messages
745
Reactions
1,848
Points
182
City
Newbury
State
Non-US
Country
United Kingdom
Vehicle
2018 Demon
#12
Sending out the "hellcat" signal to other UK members like @The Englishman, surely he may have experience with these trackers to add here.
I had to have a monitored tracker due to vehicle value,but anything will be better than nothing and for £50 the Amazon one could be money well spent.



Diboblo

2000 Posts Club
Founding Member
Wiki Contributor
Member ID
#1044
Messages
2,060
Reactions
13,954
Points
252
City
Riverside
State
CA
Country
United States
Vehicle
2015 Dodge Charger Hellcat!
#13
Check your rear power distribution block (fuse box).

Fuse 18 is set up for either switched power, or constant on. To set up for ignition switched power, remove the fuse. Looking down at it, you will notice there are 3 sockets, for that fuse. Two of them will keep the fuse in line, with the rest. Two of them will offset the fuse.

With the fuse in the offset position, the circuit is switched. This controls the power port (not the usb), in the center console. You can get a plug in USB adapter, for that port... connect to it and just leave the tracker in the console. It will charge with ignition on and standby, when ignition is off.

If you want to be discreet, you can install an add a circuit to fuse 18 and wire it to a mobile usb port, in the trunk, below the floor.

Here is a photo if my power distribution block, with an add a circuit that turns on my subwoofer amp. It is in the offset position:



Bob



The Englishman

500 Posts Club
Founding Member
Premium Account
Donating Member
9 Second Best E/T
HFCOTM
Member ID
#1082
Messages
745
Reactions
1,848
Points
182
City
Newbury
State
Non-US
Country
United Kingdom
Vehicle
2018 Demon
#14
I've a 2019 Redeye on the way, hoping for test/registration to be complete by 5th August :love:

The insurance company insists on a tracking device being fitted. They've agree to a stand alone plug in box sort as I wasn't keen on a chimp chopping into the wiring loom.

Problem is now I look at the boxes the battery life is really poor, some claim 90 days on standby but they all seem to get bad reviews. Even though they send a text when power is low I'll no doubt still forget to charge it up. I don't really want to hook it up from the battery with ignition feed.

What I'm wondering and hope you can help with is where are any USB ports, are there any in the back of the centre console or similar location where I am unlikely to want to use it? Thinking I could take the USB socket out (replace with a blank) and use for the box and also hide it in the console perhaps.

Other than that I'm contemplating using a power bank to hopefully reduce number of charges but then I'll have to locate it somewhere accessible and it doesn't seem very secure just to chuck it under a seat or in the boot.

Sorry if in the wrong section, wasn't sure where to post so chose interior.
Thanks
Heres the engineer fitting mine.




OP
Lize

Lize

Active Member
Premium Account
Member ID
#2742
Messages
354
Reactions
961
Points
117
City
Bury St Edmunds
State
Non-US
Country
United Kingdom
Vehicle
2019 Challenger WB Redeye
Thread Starter #15
What do other people in the UK do to resolve this? Around here, we have shops that specialize in stereo and alarm installations. You must have some shops like that in the UK? A do-it-yourself install may be penny wise but pound foolish?
Yes we do, its not the cost so much as not wanting someone to needlessly mess about with the wiring.

How about something like this......
it looks like you could plug it into the usb on your car and leave it hooked up. If you're going tod rive every few days, shouldn't be an issue.

https://www.amazon.co.uk/SpyTrack-N...E8XYMC7CZYP&psc=1&refRID=R2TWZW9H6E8XYMC7CZYP
Yes, thats the sort of thing I was looking at, the monthly on that ones quite high so was looking at a few alternatives.

Thanks everyone and @Diboblo, thats really handy info (y)



OP
Lize

Lize

Active Member
Premium Account
Member ID
#2742
Messages
354
Reactions
961
Points
117
City
Bury St Edmunds
State
Non-US
Country
United Kingdom
Vehicle
2019 Challenger WB Redeye
Thread Starter #16
Just thought I'd update, I got a stand alone tracker box with a battery that should last 3 years on stealth mode and pay as you go SIM card.
Got it from an auto parts store rather than from Amazon as couldn't find one with that long a lasting battery.
https://www.halfords.com/motoring/car-security/itrack-long-life-wireless-gps-tracker-407318.html

Have hidden it in the car and can now forget about it, tested a couple of times and seems to work OK.
Made in China of course.



BULL

Oh NO! Not that guy!
Staff Team
Founding Member
Premium Account
U.S. Marine Veteran
Donating Member
HFCOTM
Wiki Contributor
Member ID
#1079
Messages
11,932
Reactions
34,421
Points
402
City
Weld County
State
CO
Country
United States
Vehicle
MY16 M6 Challenger Hellcat
#17
Check your rear power distribution block (fuse box).

Fuse 18 is set up for either switched power, or constant on. To set up for ignition switched power, remove the fuse. Looking down at it, you will notice there are 3 sockets, for that fuse. Two of them will keep the fuse in line, with the rest. Two of them will offset the fuse.

With the fuse in the offset position, the circuit is switched. This controls the power port (not the usb), in the center console. You can get a plug in USB adapter, for that port... connect to it and just leave the tracker in the console. It will charge with ignition on and standby, when ignition is off.

If you want to be discreet, you can install an add a circuit to fuse 18 and wire it to a mobile usb port, in the trunk, below the floor.

Here is a photo if my power distribution block, with an add a circuit that turns on my subwoofer amp. It is in the offset position:



Bob


This got a rarely used "Bookmark" on my account.

You should feel honored and privileged both...


;)



Diboblo

2000 Posts Club
Founding Member
Wiki Contributor
Member ID
#1044
Messages
2,060
Reactions
13,954
Points
252
City
Riverside
State
CA
Country
United States
Vehicle
2015 Dodge Charger Hellcat!
#18
This got a rarely used "Bookmark" on my account.

You should feel honored and privileged both...


;)
I wait, with anticipation, for days like this...

Bob
